ESP32-WROOM-32 WT32-ETH01 Embedded Serial Port to Ethernet WiFi BT Wireless Development Module

ESP32-WROOM-32 WT32-ETH01 Embedded Serial Port to Ethernet WiFi BT Wireless Development Module

• The module integrates an optimized TCP/IP protocol stack internally, making it easy for users to complete the networking function of embedded devices, greatly reducing development time and costs.
• The module is compatible with half solder pads and connector through-hole designs, and the board width is universal.
• The module can be directly soldered onto the board, connectors can be soldered, and can also be used on breadboards, making it convenient for users to use in different scenarios.
• The ESP32 series IC is a Soc that integrates 2.4GHz Wi Fi and Bluetooth dual-mode, with good functional performance.
• The module has ultra-high RF performance, stability, versatility and reliability, as well as ultra-low power consumption.
• Product Contents:ESP32-WROOM-32 WT32-ETH01 Embedded Serial Port to Ethernet WiFi BT Wireless Development Module
• Indicator light description:
  LED1: Power indicator light, powered on normally, light on;
  LED3: Serial port indicator light, when RXD2 (IO5) has data flow, the light is on;
  LED4: Serial port indicator light, when TXD2 (IO17) has data flow, the light is on;

• Instructions for Use
  Three usage methods, users can choose according to their needs:
  1) Through hole (welding pin): connected using DuPont wire;
  2) Through hole (welding pin): used on a breadboard;
  3) Half solder pad: Users can directly solder modules onto their own boards.
  Explanation of network port working indicator light
  Green light: Connection status indicator, green light on when correctly connected to the network
  Yellow light: Data indicator, flashing when the module receives or sends data, including the module receiving network broadcast packets
